产品目录第 309 页

光谱与元素分析仪器scia Systems型号 scia Multi 680

scia Multi 680

Multilayer Coatings for Large Substrates up to 680 mm in dia.

型号: scia Multi 680
Product category: Magnetron Sputtering
Substrate size (up to): 680 mm dia., 130 kg
Sputter source: Up to 6 rectangular magnetrons (610 mm x 89 mm), ion beam source possible

查看详情

光谱与元素分析仪器scia Systems型号 scia Multi 1500

scia Multi 1500

Multilayer Coatings for Large Substrates up to 1500 mm in dia.

型号: scia Multi 1500
Product category: Magnetron Sputtering
Substrate size (up to): 1500 mm dia., 850 kg
Sputter source: 4 rectangular magnetrons (1219 mm x 89 mm) per chamber, ion beam source possible

查看详情

色谱与质谱仪器scia Systems型号 scia Magna 200

scia Magna 200

Products Ion Beam Etching Ion Beam Trimming Ion Beam Sputtering scia Cluster 200 more...

型号: scia Magna 200
Product category: Magnetron Sputtering
Substrate size (up to): 200 mm dia.
Substrate holder: Water-cooled, helium backside cooling contact, rotation up to 20 rpm, optional RF bias, electrostatic clamping and wafer heating (up to 1000 °C)

查看详情

光谱与元素分析仪器scia Systems型号 scia Magna 400

scia Magna 400 / 500 / 700 / 1200

Products Ion Beam Etching Ion Beam Trimming Ion Beam Sputtering scia Cluster 200 more...

型号: scia Magna 400
Product category: Magnetron Sputtering
Substrate size (up to): 400 mm x 200 mm, 200 mm dia. for spin rotation
Sputter source: 6 rectangular magnetrons (203 mm x 89 mm), ion source possible

查看详情

光谱与元素分析仪器scia Systems型号 scia Eva 200

scia Eva 200

Products Ion Beam Etching Ion Beam Trimming Ion Beam Sputtering scia Cluster 200 more...

型号: scia Eva 200
Product category: E Beam Evaporation
Substrate size (up to): 200 mm dia.
Substrate holder: Water-cooled, helium backside cooling contact, substrate rotation 5 to 20 rpm, tiltable in-situ from 0° to 180° in 0.1° steps, optional heating

查看详情

光谱与元素分析仪器scia Systems型号 scia Clean 800

scia Clean 800

High-Quality Cleaning and Qualification up to 800 mm in dia. and 500 mm in height

型号: scia Clean 800
Product category: Dry Cleaning
Substrate size (up to): 800 mm dia., 500 mm height, 500 kg
Substrate heating: Radiation heaters (4.5 kW) up to 250 °C

查看详情

光谱与元素分析仪器scia Systems型号 scia Clean 1000/1500/3000

scia Clean 1000/1500/3000

High-Quality Cleaning and Qualification up to 3 m in dia. and 3.4 m in length

型号: scia Clean 1000/1500/3000
Product category: Dry Cleaning
Substrate size (up to): 1000 mm dia., 850 mm length, 500 kg
Substrate heating: Radiation heaters (7.5 kW) up to 250 °C

查看详情

色谱与质谱仪器scia Systems型号 scia Batch 350

scia Batch 350

Products Ion Beam Etching Ion Beam Trimming Ion Beam Sputtering scia Cluster 200 more...

型号: scia Batch 350
Product category: Pecvd Rie
Substrate size: Individual sizes loaded on 2 carriers, carrier size up to 350 mm x 240 mm
Substrate carrier: Water-cooled, pulsed DC bias (2 kV, 400 mA)

查看详情

色谱与质谱仪器scia Systems型号 scia Cube 300

scia Cube 300

Products Ion Beam Etching Ion Beam Trimming Ion Beam Sputtering scia Cluster 200 more...

型号: scia Cube 300
Product category: Pecvd Rie
Substrate size (up to): 300 mm x 200 mm
Substrate holder: Water-cooled, RF bias

查看详情

色谱与质谱仪器scia Systems型号 scia Cube 750

scia Cube 750

Products Ion Beam Etching Ion Beam Trimming Ion Beam Sputtering scia Cluster 200 more...

型号: scia Cube 750
Product category: Pecvd Rie
Substrate size (up to): 750 mm x 750 mm
Substrate holder: Water-cooled, RF bias

查看详情

色谱与质谱仪器scia Systems型号 scia Inline 400

scia Inline 400

Products Ion Beam Etching Ion Beam Trimming Ion Beam Sputtering scia Cluster 200 more...

型号: scia Inline 400
Product category: Customized Systems
Substrate size (up to): Individual sizes loaded on carrier, carrier size up to 450 mm x 400 mm
Ion beam source: Two 380 mm linear microwave ECR sources (LIN380-e)

查看详情
